أخوانى فى الله أحضرت لكم كتاب Introduction to Solid Modeling using SolidWorks 2017 William E. Howard East Carolina University Joseph C. Musto Milwaukee School of Engineering
![كتاب Introduction to Solid Modeling using SolidWorks 2017 I_s_m_10](https://i.servimg.com/u/f61/15/36/74/14/i_s_m_10.jpg) ويتناول الموضوعات الأتية :
Special Features vii Preface ix PArt one learning SolIdWorkS 1 1 Basic Part Modeling techniques 3 1.1 engineering design and Solid Modeling 4 1.2 Part Modeling tutorial: Flange 5 1.3 Modifying the Flange 25 1.4 using dimensions and Sketch relations 30 1.5 A Part created with revolved Geometry 35 Problems 49 2 engineering drawings 55 2.1 drawing tutorial 55 2.2 creating a drawing Sheet Format 71 2.3 creating an edrawing 77 Problems 82 3 Additional Part Modeling techniques 85 3.1 Part Modeling tutorial: Wide-Flange Beam Section 86 3.2 Part Modeling tutorial: Bracket 94 3.3 Sharing and displaying the Solid Model 108 Problems 112 4 Advanced Part Modeling 119 4.1 A lofted and Shelled Part 119 4.2 Parts created with Swept Geometry 130 4.3 A Part created with a 3-d Sketch as the Sweep Path 135 Problems 142 5 Parametric Modeling techniques 151 5.1 Modeling tutorial: Molded Flange 152 5.2 creation of Parametric equations 165 5.3 Modeling tutorial: cap Screw with design table 169 5.4 Incorporating a design table in a drawing 176 Problems 184 6 creation of Assembly Models 191 6.1 creating the Part Models 191 6.2 creating a Simple Assembly of Parts 196 6.3 Adding Features at the Assembly level 205 6.4 Adding Fasteners to the Assembly 207 6.5 creating an exploded View 212 Problems 217 c o n t e n t S v7 Advanced Assembly operations 227 7.1 creating the Part Models 227 7.2 creating a complex Assembly of Subassemblies and Parts 228 7.3 detecting Interferences and collisions 234 Problems 236 8 Assembly drawings 239 8.1 creating an Assembly drawing 239 8.2 Adding an exploded View 241 8.3 creating a Bill of Materials 244 Problems 248 PArt tWo Applications of SolIdWorkS 251 9 Generation of 2-d layouts 253 9.1 A Simple Floor Plan layout 253 9.2 Finding the Properties of 2-d Shapes 266 Problems 271 10 Solution of Vector Problems 275 10.1 Vector Addition 275 10.2 Vector Addition with SolIdWorkS 276 10.3 Modifying the Vector Addition drawing 278 10.4 Further Solution of Vector equations 281 10.5 kinematic Sketch of a Simple Mechanism 284 Problems 292 11 Analysis of Mechanisms 295 11.1 Approaching Mechanism design with SolIdWorkS Assemblies 296 11.2 development of Part Models of links 297 11.3 development of the Assembly Model of the Four-Bar linkage 300 11.4 creating Simulations and Animation with a Motion Study 304 11.5 Investigating Mechanism design 309 Problems 315 12 design of Molds and Sheet Metal Parts 325 12.1 A Simple two-Part Mold 325 12.2 A core-and-cavity Mold 330 12.3 A Sheet Metal Part 338 Problems 347 13 the use of SolIdWorkS to Accelerate the Product development cycle 351 13.1 Additive Manufacturing 352 13.2 Finite element Analysis 357 13.3 Product data Management 358 13.4 Some Final thoughts 360 APPendIx A recommended Settings 361 A.1 System Settings 361 A.2 Part Settings 362 A.3 drawing Settings 365 A.4 Assembly Settings 366 A.5 Backing up and transferring Settings 367 A.6 Summary of recommended Settings 369 B the SolIdWorkS Interface: use and customization 371 Index 381 vi contentsvii deSIGn Intent Planning the Model 18 Selecting a Modeling Technique 24 Planning for Other Uses of the Model 40 Choosing the Initial Sketch Plane 42 Keeping It Simple 46 Exploiting Associativity 62 Symmetry in Modeling 106 Planning an Assembly Model 198 Part-Level and Assembly-Level Features 208 Manufacturing Considerations 214 Assembly-Level Dimensions 242 Future Study Dynamics (Kinetics) 47 Manufacturing Processes, Geometric Dimensioning and Tolerancing, and Metrology 67 Industrial Design 129 Industrial Engineering 265 Mechanics of Materials 269 Machine Dynamics and Machine Design 310 Materials and Processes 337
كلمة سر فك الضغط : books-world.net The Unzip Password : books-world.net أتمنى أن تستفيدوا من محتوى الموضوع وأن ينال إعجابكم رابط من موقع عالم الكتب لتنزيل كتاب Introduction to Solid Modeling using SolidWorks 2017 رابط مباشر لتنزيل كتاب Introduction to Solid Modeling using SolidWorks 2017 ![](https://i.servimg.com/u/f61/15/36/74/14/sign_110.gif)
|
|
